PMPB15XP
main product photo

The image is for reference only

Please refer to the product specifications

PMPB15XP
  • SKU:
    PMPB15XPH
  • Short Description:
      12 V, single P-channel Trench MOSFET
  • Description:


    P-channel enhancement mode Field-Effect Transistor (FET) in a leadless medium power DFN2020MD-6 (SOT1220) Surface-Mounted Device (SMD) plastic package using Trench MOSFET technology.

  • Datasheet:
    Download the Datasheet
Stock: 99999999
Qty:
Price: $0.1116
Total: $0.1116
Price
Qty Price Total price
1 $0.1116 $0.1116
500 $0.1014 $50.7000
1000 $0.0966 $96.6000
3000 $0.092 $276.0000

Features

  • 1.5 kV ESD protection (human body model)

  • Trench MOSFET technology

  • Small and leadless ultra thin SMD plastic package: 2 x 2 x 0.65 mm

  • Exposed drain pad for excellent thermal conduction

  • Tin-plated 100 % solderable side pads for optical solder inspection

Applications

  • Charging switch for portable devices

  • DC-to-DC converters

  • Power management in battery-driven portable devices

  • Hard disk and computing power management

Datasheet
Download the Datasheet
